    IT-SC200T

    Review (0)

    Power (HP): 2
    Power (KW): 1,5
    Head min. (Mt.): 11
    Head max. (Mt.): 30
    Capacity min Q. (Lt/Min.): 50
    Capacity max Q. (Lt/Min.): 450
    DNA: 2"
    DNM: 2"
    Pump weight (Kg): 20,9
    Voltage: three phase 230/400 V - 50 Hz

    Color :
    Delivery time

    1 - 10 pieces: 7/10 days, transport included;
    11 - 50 pieces: 15 days, transport included;
    51 - 100 pieces: 25 days, including transport;
    over 100 pieces: estimated 30 days.

    All products are made in Italy and are produced, assembled and checked with the identification serial number placed on the accompanying booklet and reserved for the customer-order number.

    REQUEST FOR QUOTATION

    • Politiche per la sicurezza (modificale con il modulo Rassicurazioni cliente)
    • Delivery time 6 weeks All products are made in Italy and are produced, assembled and checked with serial number
    • Politiche per i resi merce (modificale con il Modulo rassicurazioni cliente)

    SCOPE OF APPLICATION: Opened impeller pump with axial intake and upward-facing radial delivery. These pumps feature high flow rate values and medium-low discharge heads and are particularly suited for pumping up unclean water, with temperature not higher than 80°C. The opened impeller allows any solid matter up to 8 mm. in diameter to pass through without causing any damage to the pump.

    PUMP: Horizontal axis pump with bronze impeller (SA/SAM 1C-1-2) or cast iron (SA/SAM 1/A-2/A), pump body and base support made of G20 cast iron, AISI 416 stainless steel shaft and mechanical seal made of ceramic/graphite.

    MOTOR: Electric, closed-type with external cooling fan, IP 44 safety class. F insulation. The standard versions of single-phase motors are fitted with termostat-controlled safety microswitches to avoid undesirable damages to the motor. The user must provide protection for three-phase electropumps.

    TENSION: SAM: 230-240 V. 50 Hz; SA: 230/400 V. 50 Hz. Different voltage and frequency ratings are available on request.

    APPLICATIONS: Irrigation, Agriculture, Industry

    IT-SC200T

    Data sheet

    Power (HP)
    2
    Power (kW)
    1,5
    Head min (Mt.)
    11
    Head max (Mt.)
    30
    Capacity min Q. (Lt/Min.)
    50
    Capacity max Q. (Lt/Min.)
    450
    DNA
    2"
    DNM
    2
    Pump weigth (Kg)
    20,9
    Voltage
    Three-phase 230/400 V - 50 Hz
