DOUBLE IMPELLER SELF-PRIMING JET PUMPS

Power (HP): 3 Power (KW): 2,2 Head min. (Mt.): 40 Head max. (Mt.): 64 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 120 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 32,1 (brass impeller) / 31 (noryl impeller) Voltage: single phase 230/240 V - 50 Hz

Mixed items

IT-NPM7B

IT-NPM B

Power (HP): 3 Power (KW): 2,2 Head min. (Mt.): 40 Head max. (Mt.): 64 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 120 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 32,1 (brass impeller) / 31 (noryl impeller) Voltage: single phase 230/240 V - 50 Hz

Mixed items

IT-NP5B

IT-NP B

Power (HP): 1,5 Power (KW): 1,1 Head min. (Mt.): 35 Head max. (Mt.): 60 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 80 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 29,4 (brass impeller) / 28,3 (noryl impeller) Voltage: three phase 230/400 V - 50 Hz

Mixed items

IT-NP5B

IT-NP B

Power (HP): 1,5 Power (KW): 1,1 Head min. (Mt.): 35 Head max. (Mt.): 60 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 80 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 29,4 (brass impeller) / 28,3 (noryl impeller) Voltage: three phase 230/400 V - 50 Hz

Mixed items

IT-NP6B

IT-NP B

Power (HP): 1 Power (KW): 1,5 Head min. (Mt.): 40 Head max. (Mt.): 60 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 100 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 30,5 (brass impeller) / 29,2 (noryl impeller) Voltage: three phase 230/400 V - 50 Hz

Mixed items

IT-NP6B

IT-NP B

Power (HP): 1 Power (KW): 1,5 Head min. (Mt.): 40 Head max. (Mt.): 60 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 100 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 30,5 (brass impeller) / 29,2 (noryl impeller) Voltage: three phase 230/400 V - 50 Hz

Mixed items

IT-NPM6B

IT-NPM B

Power (HP): 1 Power (KW): 1,5 Head min. (Mt.): 40 Head max. (Mt.): 60 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 100 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 31,4 (brass impeller) / 30 (noryl impeller) Voltage: single phase 230/240 V - 50 Hz

Mixed items

IT-NPM6B

IT-NPM B

Power (HP): 1 Power (KW): 1,5 Head min. (Mt.): 40 Head max. (Mt.): 60 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 100 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 31,4 (brass impeller) / 30 (noryl impeller) Voltage: single phase 230/240 V - 50 Hz

Mixed items

IT-NP7B

IT-NP B

Power (HP): 3 Power (KW): 2,2 Head min. (Mt.): 40 Head max. (Mt.): 64 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 120 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 31,1 (brass impeller) / 30 (noryl impeller) Voltage: three phase 230/400 V - 50 Hz

Mixed items

IT-NP7B

IT-NP B

Power (HP): 3 Power (KW): 2,2 Head min. (Mt.): 40 Head max. (Mt.): 64 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 120 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 31,1 (brass impeller) / 30 (noryl impeller) Voltage: three phase 230/400 V - 50 Hz

Mixed items

IT-NPM5B

IT-NPM B

Power (HP): 1,5 Power (KW): 1,1 Head min. (Mt.): 35 Head max. (Mt.): 60 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 80 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 29,4 (brass impeller) / 28,3 (noryl impeller) Voltage: single phase 230/240 V - 50 Hz

Mixed items

IT-NPM5B

IT-NPM B

Power (HP): 1,5 Power (KW): 1,1 Head min. (Mt.): 35 Head max. (Mt.): 60 Capacity min Q. (Lt/Min.): 10 Capacity max Q. (Lt/Min.): 80 DNA: 1" 1/2 DNM: 1" Pump weight (Kg): 29,4 (brass impeller) / 28,3 (noryl impeller) Voltage: single phase 230/240 V - 50 Hz

Mixed items
